| Specification | Bed Length – 250U mm | |
|---|---|---|
| Capacity | Maximum Swing | 580 mm |
| Maximum Machining Diameter | 250 mm | |
| Maximum Bar Work Capacity | 51 mm | |
| Maximum Machining Length | 264 mm | |
| Main Spindle | Chuck Size | 8 in |
| Maximum Speed | 4000 rpm | |
| Turret (Upper) | Number of Tools | 8 |
| Feed Axes | Travel (X Axis) | 140 mm |
| Travel (Z Axis) | 305 mm | |
